1.PRP: Prime Power is available for an unlimited number of annual operating hours in variable load applications, in accordance with ISO8528-1. A 10% overload capability is available for a period of 1 hour within 12-hour period of operation. In accordance with ISO 3046-1.

2.ESP: The Standby Power Rating is applicable for supplying emergency power in variable load applications for up to 200 hours per year in accordance with ISO8528-1. Overload is not allowed.

ENGINE

ALTERNATOR

CONTROL SYSTEM

Control supervision and protection panel；mounted；genset base frame；The control panel；equipped as follows：

Features:
◆ The module is used to monitor main supply and starts and stops of a standby generating set
◆ Micro-processor based design
◆ Automatic control of main and generator contactors
◆ Monitors engine performance and AC power output LED alarm indication
◆ Front panel configuration of timers and alarm trip points
◆ 4 configurable analogue/digital inputs，8 configurable digital inputs
◆ 6 configurable DC outputs
◆ Easy push button control STOP/RESET - MANUAL - AUTO - TEST – START


Metering via LCD display:
◆ Generator Volts (L-L / L-N) Generator kVA
◆ Engine oil pressure (PSI-Bar) Generat
◆ Engine temperature (°C&°F)
◆ Generator Frequency (Hz)
◆ Plant battery volts
◆ Engine hours run
◆ Mains Volts (Ph-Ph/Ph-N)

Alarms:
◆ Over and Under Speed
◆ Low and High Battery Volt.
◆ Engine temperature (°C&°F)
◆ Start and Stop Failure
◆ Charge fail
◆ Over Current
◆ Under / Over Generator Voltage
◆ Low Oil Pressure
◆ Emergency stop
◆ High engine temperature

BASIC OPEN TYPE CONFIGURATION


◆ Cummins diesel engine with mechanical governor system
◆ Maintenance-free battery,
◆ Brushless self-excited alternators with AVR controlled,
◆ LCD control panel,
◆ Replaceable fuel filter, oil filter,dry element air filter
◆ Main circuit breaker and relays, and fuel-water separator filter,
◆ 8 hours fuel tank base,
◆ Original Cummins Radiator c/w Piping Kit,
◆ Electronic fuel level sensor on the fuel tank,
◆ Industrial capacity exhaust silencer and steel bellows,
◆ Anti-vibration mountings,
◆ Flexible fuel connection hoses and manual oil sump drain
◆ Operation manuals and circuit diagram documents, valve,
◆ Factory test certificate.

OPTIONAL CONFIGURATION


◆Coolant heater,
◆ Battery charger,
◆ Oil heater,
◆ Automatic transfer switch,
◆ Anti-condensation heater,
◆ Residential silencer,
◆ Extra filters for future maintenance,
◆ Galvanzied sound attenuated canopy,
◆ ComAp,Smartgen control system,
◆ Standard sound proof 20ft/40ft container,
◆ Trailer.

DIMENSION
